3a. Mount on Wood Stud Wall
• Make sure that mounting screws are anchored into the center of the studs.
Use of a stud finder is highly recommended.
• Installers are responsible to provide hardware for other types of mounting situations.
• Installers must verify that the supporting surface will safely support the combined
load of the equipment and all attached hardware and components.
13-08-142-933298.indb 5
Downloaded from
www.Manualslib.com
Anchor Bolt
manuals search engine
1
WARNING
5
2
Find and mark the exact
location of mounting holes
3
Drill pilot holes
Screw the wall
plate onto the
wall
8/13/2013 12:56:25 PM
