Operating instructions SATA air check set
EN
connected components for any signs of damage and ensure it is fitted
firmly; carry out any necessary repairs.
Operating parameters
■ The air check set may only be operated with the stated parameters (see
chapter 7).
Connected components
■ Only use original SATA accessories and spare parts.
■ The connected hoses and lines must reliably withstand the thermal,
chemical and mechanical loads expected during operation.
■ When pressurised hoses work loose, their whip-like movements can
cause injuries. Always vent the hoses completely before they are loos-
ened.
Cleaning
■ Never use acidic or alkaline cleaning agents to clean the air check set.
■ Never use cleaning agents based on halogenated hydrocarbons.
General
■ Comply with the local regulations for safety, accident prevention, occu-
pational health and safety and environmental protection.
■ Heed the accident prevention regulations.

3. Intended Use

The air check set serves to check the air pressure quality in pipes, filters
and hoses.

4. Description

The compressed air required for checking is supplied at the connection
nipple. Fully variable adjustment of the test air is possible at the com-
pressed air control button. After 10 minutes, end the test, disconnect the
air check set from the compressed air circuit and check the test mem-
brane for visual soiling.

5. Scope of Delivery

■ Air check set with pressure gauge, sintered filter, O-ring and connection
nipple
■ Pincers
■ Magnifying glass
■ Lamp
■ Test membranes (10 each)
■ Operating Instructions
