1.2 Speciications
Platform
CPU
Chipset
Memory
Expansion
Slot
Graphics
6
• Mini-ITX Form Factor
• Solid Capacitor design
• High Density Glass Fabric PCB
• Supports 6 th
Generation Intel® Core
Celeron® Processors (Socket 1151)
• Digi Power design
• 6 Power Phase design
• Supports Intel® Turbo Boost 2.0 Technology
• Intel ®
H170
• Supports Intel® Small Business Advantage 4.0
• Dual Channel DDR4 Memory Technology
• 2 x DDR4 DIMM Slots
• Supports DDR4 2133 non-ECC, un-bufered memory
• Max. capacity of system memory: 32GB
• Supports Intel® Extreme Memory Proile (XMP) 2.0
• 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)
• 1 x Vertical Half-size Mini-PCI Express Slot
* his Mini-PCI Express Slot supports WiFi and mSATA
devices.
• Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
Technology, Intel® Insider
• Pixel Shader 5.0, DirectX 12
• Max. shared memory 1792MB
• Dual graphics output: Support DVI-D and HDMI ports by
independent display controllers
TM
i7/i5/i3/Pentium®/
TM
3D, Intel® Clear Video HD
TM
, Intel® HD Graphics 510/530
