Preface
Many thanks for purchasing this Steinbach product. We continually
develop and enhance our items, however, should this product be faulty,
we apologise for any inconvenience and politely ask you to get in
contact with our service centre.
Read operating manual and store safely
Instruction manual for Filter unit Miganeo Speed Clean 7000.
This instruction manual relates to the product stated above. It contains
important information on starting your product for the fi rst time and how
to operate it. Carefully read through the instruction manual - particularly
the safety instructions - before using this product. Non-compliance with
this instruction manual may lead to major injuries or damage to your
product. The instruction manual is based on standards and regulations
applicable within the European Union. If the product is being used
abroad, please follow any country-specifi c guidelines and laws. Store
the instruction manual in a safe location for later consultation and
submission to third parties, where applicable.
Intended use
This product is solely intended for private use and is not suitable for
commercial use.
The fi lter system has been designed exclusively to clean pool water
and to remove visible impurities. The system is suitable for all standard
swimming pools which have a 32/38 mm diameter hose connection.
Only use the product as described in this instruction manual. Any other
use is considered improper use and may lead to personal injury or
damage to property. This item is not a toy. The manufacturer or retailer
assumes no liability for damage resulting from improper or incorrect
use.
Warnings and safety instructions
Read and observe all instructions. Non-compliance with these
warnings and instructions may result in damage to property,
severe personal injury or even death. These product warnings,
instructions and safety regulations are extensive but cannot cover
all potential risks and dangers and are thus not to be considered
exhaustive. Please be cautious and assess potential dangers
appropriately. Incorrect use/handling of the product can lead to
life-threatening situations.
Caution! Leave repairs to experts in order to prevent hazards.
Consult a specialist workshop. Liability is waived and warranty
claims expire if repairs are carried out independently of if the
product is improperly installed or used incorrectly. Only original
parts corresponding to the original product specifi cations may be
used during repairs.
WARNING! Hazardous for children and persons with reduced
physical, sensory or mental abilities (such as the handicapped,
elderly individuals with impaired physical and mental abilities),
or those with a lack of experience and knowledge. Children must
not be allowed to play with this product. Cleaning may not be
performed by children and persons with reduced physical, sensory
or mental abilities.
NOTE! Risk of damage! This product may be damaged through
improper use.
Danger of electrocution! Faulty electrical installation or too
high mains voltage can lead to electrocution. Only connect the
product if the mains voltage on the socket corresponds to the
technical specifi cations. Only connect this product using an
easily accessible socket to ensure it can be rapidly disconnected
from the mains in the event of a fault. Do not operate the product
if it exhibits visible damage or the mains cable/plug is defective.
As additional protection, it is recommended to install a residual
current device (FI/RCD) with a tripping current of no more than 30
mA. Consult with an electrician for advice.
Only open the product as described in this manual. Leave repairs
to experts in order to prevent hazards. Consult a specialist
workshop. Liability is waived and warranty claims expire if repairs
or changes to the product are carried out independently of if
the product is improperly connected or operated incorrectly.
040390GH/GH1/GP/GM_v2001
This product features electrical and mechanical parts which are
indispensable for protecting against potential hazards.
Never touch the plug with wet hands. Never pull out the plug
from the socket using the cable - always pull on the plug. Keep
the product, plug and all cables away from open fi res and hot
surfaces. Lay the cable so that it does not pose a tripping risk
and do not place it under the ground. Lay cables in such a way
that they will not be damaged by lawn mowers and other similar
devices. Do not kink the cable and do not lay it over sharp edges.
Do not use an extension cable, multiple socket adapters or other
adapters.
Filtration systems must not be operated dry (i.e. without any
water)! The water has a cooling effect - if used without water, there
is no warranty protection! Never place the pump or fi lter into the
pool. The fi lter pump must be switched off before every switching
operation using the 7-way valve! The fi ltration system must not be
used if there are people in the water! Install the fi ltration system
at a suitably safe distance from the pool to prevent children using
the system as a means of entering the pool. Do not submerge the
fi ltration system, mains cable or plug in water or other liquids. The
fi lter pump of the fi ltration system is to be protected from foreign
bodies and splashes of water. It is still worthwhile to install it in
such a way that it is also protected from the weather. Never carry
out any work on the fi ltration system while it is still connected to
the mains. Hazards posed by the suction of the pump can lead to
serious injury and death if adequate precautions are not taken. Do
not block the suction openings on the pump or in the pool since
this may lead to serious injury or even death.
Check scope of delivery
NOTE! Risk of damage! The product may be damaged if you open the
packaging with a sharp knife or other sharp objects without due care
and attention. Please open the packaging very carefully.
■ Remove the product from the packaging.
■ Check that all included items have been delivered in full. Sketch/photo
L1.
■ Check whether the item, or parts thereof, exhibit damage. If there
is damage, do not use the product. Get in contact with the service
address stated at the end of the manual.

Operation

The quartz sand used in the fi lter system's tank provides long-lasting
fi ltration of dirt particles and fl oating debris. Dirty water is drawn from
the pool via the suction pipe through the fi lter pump and then fed
directly from above through the 7-way valve into the fi lter tank. As
the water fl ows through the quartz sand in the fi lter tank, dirt particles
are deposited in the sand and thus fi ltered out of the pool water. The
purifi ed water fl ows through the 7-way valve back into the pool via the
return pipe.
For the operation of the fi lter system, you need a skimmer (surface
skimmer). Either an integrated skimmer (built into the pool wall) or a
suspended skimmer (attachment to the poolwall).
Filter sand requirements
■ Only quartz sand can be used with this fi lter system. The quartz sand
must comply with the DIN 12904 quality standard.
Positioning
The installation area you set between the skimmer and the inlet nozzle
so, that there is an adequate safety margin to the pelvic wall. We
recommend putting the fi lter system in addition on base plates (for
example: washed concrete slabs etc.). These have to be installed with
the spirit level. Under no circumstances you may put your fi lter system
in a trough or directly into the grass (fl ood danger or risk of overheating
of the fi lter pump).
If you have sunk your pool partially or completely, so it makes sense to
place the fi lter pump in a fi lter slot, which should connect directly to the
