The R65 LED Beacon features 9 powerful LED's arranged to produce a
360° flash pattern, with a flash rate of 125FPM for maximum visibility. This
Beacon is suitable for applications where the UK lighting regulation Chapter
8 is a requirement*. Combining the solid state, maintenance free and long
life nature of LED technology with a proven tough housing design. This
ECCO beacon is designed to maximise resilience to excessive vibration
and increase the life of the product.
* - Amber version only.
Failure to install or use this product according to manufacturers recommendations may result in property damage,
serious injury, and/or death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the
safety information contained in this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning
devices are essential to ensure the safety of you and those you are seeking to protect.
2. Exercise caution when working with live electrical connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can
cause high current arcing, which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation are vital to the performance of this warning device. Install this product so
that output performance of the system is maximized and the controls are placed within convenient reach of the
operator so that s/he can operate the system without losing eye contact with the roadway.
5. Do not install this product or route any wires in the deployment area of an air bag. Equipment mounted or
located in an air bag deployment area may reduce the effectiveness of the air bag or become a projectile that
could cause serious personal injury or death. Refer to the vehicle owner's manual for the air bag deployment
area. It is the responsibility of the user/operator to determine a suitable mounting location ensuring the safety
of all passengers inside the vehicle particularly avoiding areas of potential head impact.
6. It is the responsibility of the vehicle operator to ensure during use that all features of this product work
correctly. In use, the vehicle operator should ensure the projection of the warning signal is not blocked by
vehicle components (i.e., open trunks or compartment doors), people, vehicles or other obstructions.
7. The use of this or any other warning device does not ensure all drivers can or will observe or react to a warning
signal. Never take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before
entering an intersection, driving against traffic, responding at a high rate of speed, or walking on or around
traffic lanes.
8. This equipment is intended for use by authorized personnel only. The user is responsible for understanding
and obeying all laws regarding warning signal devices. Therefore, the user should check all applicable city,
state, and federal laws and regulations. The manufacturer assumes no liability for any loss resulting from the
use of this warning device.
Important!
This unit is a safety device and it must be
connected to its own separate, fused power point to assure its
continued operation should any other electrical accessory fail.
Page 1 of 3
P/N 920-0651-00 (Rev A) 2017-06-06
© 2017 at ECCO
Installation and Operation
Instructions
R65* LED Beacon
Caution:
When drilling into any vehicle surface, make sure
the area is free from any electrical wires, fuel lines, vehicle
upholstery, etc. that could be damaged.
