Installing the Vehicle Cradle
1 Attach the RAM cradle base to the vehicle cradle using the
2 Attach the RAM vehicle base to your vehicle using the four
3 Attach the vehicle cradle to the RAM vehicle base by placing
4
Downloaded from www.Manualslib.com
four button head hex screws and the hex key.
¼-inch-flathead hex screws and nuts.
the mounting arm over the two bases and then tightening the
mounting arm.
Cradle
Mounting arm
base
manuals search engine
Vehicle
cradle
Hex screw
(4 places)
Vehicle
cradle
Cradle base
Vehicle
base
