Installation; Connecting Equipment - LevelOne GEP-0950 Schnellinstallationsanleitung

ENGLISH

Installation

Power
Link/Act
LED Indicator
Status
LED Indicator
On Power is on.
Power
Off Power is off.
On Port is connected
Blinking Transmitting / Receiving data
Link/Act
Off Port is not connected

Connecting Equipment

Step1. Inspect the Power Adapter carefully, and make sure
that it is properly connected to a power source.
Step2. Plug-in the Power Adapter to the Switch.
Step3. Connect your network devices with the switch by
using Ethernet cable. (e.g. Cat-5e)
SFP
Meaning
