English - Limit 2000 Handbuch

Specification
Memory for max, min and last value.
Tachometer Contact
Tachometer Photo
Surface speed
Accuracy Tachometer
Accuracy Surface speed
Reading
Battery
Tachometer contact measuring.
Choose correct adapter for best application against centre of
rotating object and apply it to upper cover ring.
Push front button and select CONTACT with select button.
Push side button and lightly press the adapter to the centre of the
rotating object. Release side button when the reading has stabilize
in approx 2 seconds.
Tach 2,5 -1000 rpm
Tach over 1000 rpm
Speed 0,005 -100 m/min
Speed over 100 m/min
4 pcs 1,5 V Type AA.
2

English

2,5 – 20 000 rpm
2,5- 100 000 rpm
0,05 – 2 000 m/min
(0,2 – 6560 ft/min)
± 0,05 % + 1 rpm
± 0,05 % + 0,1 m/min
0,1 rpm
1 rpm
0,01 m/min
0,1 m/min
