1 POWER – Press this button to switch the unit on or off
(the mains switch fitted on the back of the unit must be in the ON position).
2 INPUT – Press one of these buttons to select the signal source
the front display LED will flash once to acknowledge your selection).
COAX = Digital coax input
OPT = Digital optical input
AUX = Analog stereo signal input
= Bluetooth function. Sound reproduction will commence as
soon as the pairing with a transmitter has been completed.
The pairing will remain set up even if the inputs are changed,
provided that the transmitter remains in range of the
MAGIQUE and has not been switched off.
3 CODE - Press this button to establish a link with a smart phone or a PC. The blue
front display LED will start to flash rapidly and your MAGIQUE will send a pairing
code to the Bluetooth transmitter to establish the link.
(See: Installing chapter)
4 VOLUME – Press the '+' or '–' buttons to increase or decrease the volume.
5 BASS – Press the '+' or '–' buttons to increase or decrease the amount of bass.
6 TREBLE – Press the '+' or '–' buttons to increase or decrease the level.
7 MUTE – Press this button to "mute" the unit. Press the button once again to switch the
function off.
8 SURR – Press this button to switch on a simulated surround sound.
9 EQ-RESET – Press this button to cancel all of the tone settings (BASS/TREBLE).

Ambient conditions

The remote control has a range of up to 6 m and works without any problems from
a radiating angle of up to 30° in relation to the front of the equipment. Dust on the
transmitter or dirt on the receiving sensor and operating it in the vicinity of fluorescent
lights might reduce the range. A direct line-of-sight connection between the transmitter
and the receiver is needed.
16
Notes about the removal and the correct
environmentally-friendly disposal of
old batteries
Notes about the removal and the correct environmentally-friendly disposal of old batteries
The symbol shown here can be found on the equipment's enclosure, the packaging as
well as in the documents or the operating manual. It tells you that batteries provided
with the equipment as well as those supplied with or fitted in other units must never be
disposed of in household waste. They must be disposed of in an environmentally-friendly
way (in compliance with the local regulations or European Directives 2002/96/EU and
2006/66/EU).
You should find out where the nearest collection point for electronic scrap is or where
the recycling site is. Correct disposal of the equipment and the batteries will help to
preserve our resources and prevent physical and environmental damage. The battery
(CR2025) supplied with the remote control contains lithium and it must be disposed of in
an environmentally-friendly way as described above.
Proceed as described in the following section to replace or remove the battery fitted in
the remote control.
Push small tab forward battery Remove battery.
slot.
You must ensure that the new battery's polarity is correct when you fit the new one! The
side of the battery marked with a '+' sign / inscription must be pointing upwards when
it is fitted in the battery compartment!
Insert battery with (+) side up, and
slide drawer back.
