1. Check that all of the devices are switched off.
2. Use the mains cable that we have provided to connect up the unit to the mains power
supply.
3. Now connect up all of your other devices (TV, DVD player, etc.)
4. Use the mains switch at the back of the unit to switch the unit on.
5. Press the POWER button (1) on the remote control first and then press the button (2)
to select the source that you want to use.
6. Bluetooth connection
7. The display LED will flash rhythmically if the
x on). The link will be established automatically if the
the MAGIQUE previously and the blue display LED will be permanently lit.
8. Press the " CODE" button (3) on the remote control if you want to establish a new
link with a unit. The display LED will then flash rapidly and your MAGIQUE will
send out a pairing signal to establish the link.
9. "quadral MAGIQUE" will now be displayed on your Bluetooth device's display and
the link will be permanently established after you have confirmed the link to this unit
and the blue display LED on your MAGIQUE will be continuously lit.
10.You can change the volume from your
using the buttons (4) on your remote control.
You do not need to enter a PIN code to pair up your MAGIQUE to a smart phone
or PC if they use BT standard v2.1 or later. You should enter a "0000" PIN code for
pairing up if version 2.0 or older is being used.
Only a single device can be paired up to your MAGIQUE at the present moment.
18
Installing
input is selected (2 x on / pause / 2
source has been linked up to
device (smart phone or PC) as well as by
Note:
Specifications MAGIQUE
Power
Stereo bi-amping circuit
Harmonic distortion (Klirr)
Frequency response
Inputs
Analog
Digital
Bluetooth
Equipping
Woofer per channel
Midranges per channel
Tweeter per channel
Remote control
Dimensions
Height
Width
Depth
4 x 20 Watt / 4 Ohm
2 x 20 Watt per channel
< 1%
55 Hz – 25,000 Hz
2 x RCA
1 x optical / 1 x coaxial
Yes
1 x 150 mm
2 x 65 mm
19 mm silk dome
Infrared
104 mm
600 mm
363 mm
