Virginia closed
11 01 70xx
By Quax nv
Karel Picquélaan 84
B-9800 Deinze
T
00 32 9 380 80 95
4. Assembling the babybed
Step 1 : Connect the lateral frames (2) with the leg frames (1) while using 8 bolts (A), 8 cylindrical dowels
(B) and the hexagonal key (C).
Push 8 bolts in the provided openings (a) on the upperside and the underside of the leg frames (1). Insert
the lateral frames (2) between the legstructures and pull the bolts one by one backwards and push them
back into the openings of the sides. The sides are now hanging free between the legs.
Insert one by one the cylindrical dowels in the provided openings (c) of the sides (2). Pay attention that
the opening in the dowel faces the bolt. Tighten slightly with the hexagonal key. Repeat this action for the
remaining 7 bolts. Finally tighten fi rmly.
Step 2 : Use the parts of step 1, the matress support (3), 4 bolts (A), 4 cylindrical dowels (B) and the
hexagonal key (C).
Insert the mattress support (3) into the bed and connect it in the same manner as for the side frames.
Push 4 bolts in the provided openings (b) on the leg frames (1). Use the same height. Insert one by one
the cylindrical dowels in the provided openings (k) on the bottom of the mattress support (3). Pay attention
that the opening in the dowel faces the bolt. Tighten slightly with the hexagonal key. Repeat this action for
the remaining 3 bolts. Finally tighten fi rmly.
Step 3 : Changing the position of the mattress support.
To change the position of the mattress support you need to unscrew it. Reposition it on one of the three
positions marked by the holes (b) on the leg frames and refasten it following step 2.
Kinderbed met verstelbare bodem
Lit enfant avec fond règlable
17
Kinderbett mit verstelbarer Boden
Babybed with adjustable bottom
info@basicbaby.be
www.basicbaby.be
