SAFETY ADVICE

• The mounting must only be done by experts.
• Warning: defective mounting is dangerous!
• Check whether the wall is suitable for the mounting and
that the fasteners are strong enough for the forces involved.
• Please read through the mounting instructions carefully
before mounting in the bathroom.
• The enclosed fastening material is only suitable for solid
walls of sufficient load-bearing strength.
• If the nature of the wall is different (e.g. plasterboard or
lightweight walls), a different fastening which is suitable for
the load should be chosen by the customer.
• Electrical installations should only be carried out by a
specialist electrician DIN VDE 0100-701 (VDE 0100-701):2008-10.
• Electrified, mirrored cabinets and flat mirrors must be locat-
ed at a minimum distance of 600 mm away from the bath or
shower.
• The safety regulations and standards of the particular coun-
tries must be observed.
IMPORTANT INFORMATION
• Inspect the packaging for external damage when it is deliv-
ered.
• Please check the number of bathroom cabinets supplied and
the associated sets of ironmongery (screws, cover caps,
handles, etc.) against the delivery note or the article's label
on the packaging.
• Caution: only remove the protective caps on the mirrored
cabinet's doors after mounting the doors, in order to avoid
damaging edges of the mirrors.
• Use suitable spacers or distance blocks to even out the
existing differences in level caused by coverings applied to
the walls, e.g., partial tiling.
• Reinforce any walls of insufficient load-bearing strength.
• The drilled dimensions are measured from the FFL according
to the dimensioned layout.
• Fasten the cabinets with the suspension rails:
- Washstand base cabinet
• The horizontal spacing between the cabinets can be chosen
freely.
• Note the different suspension height for the mirrored cabinet
and the flat mirror.
• Always fasten the hanging bar to the wall with 2 screws!
• Bonding between washstand and shelf with silicone
(transparent and solvent-free).
• Only attach the glass panels after assembling the furniture!
TOOLS
• Drill and battery-operated screwdriver
• Stone drill bit of 8 mm dia
• Wood drill bit of 4 mm dia, 5mm dia
• Folding metre rule and measuring tape
• Spirit level
• Screwdriver with a 3.5 mm tip for Phillips screws
• Screw clamps
• Pencil
• Silicone sealant (transparent and solvent-free)
Ice Line

MAINTENANCE INSTRUCTIONS

• Caution: do not use any chemicals, aggressive detergent
paste or scouring powder.
• The best way of cleaning the cabinet is to use a damp cloth
with some mild washing-up liquid.
• Take care that no residue from droplets remains on the lower
edge of bathroom cabinets.
• Polish the mirror with a damp cloth or chamois leather.
• The washbasin can be easily cleaned with any of the usual,
non-abrasive cleaning agents.
• Ventilate regularly in order to prevent the mould from forming.
KEEP THE INSTRUCTIONS IN A SAFE PLACE
i
Caution: keep the instructions safely because they contain
information about installing and operating the products.
MOUNTING SEQUENCE
i
For the figures, see the attachment
1. Remove the doors and drawers (Fig. A/A1)
2. Mount the mirror grip (Fig
.
3. Mount the lamps (Fig. C/C1)
۰ The mains wire should not be live!
۰ Do not overtighten the acryl panel light!
4. Hang up the furniture (Fig. D/D1/D2/D3)
۰ Mirrored cabinet or flat mirror
۰ Tall cabinets, Upper cabinets, centre cabinets
۰ Highboard
۰ Shelves
۰ Washstand vanity unit
۰ Base cabinets
5. Align furniture (Fig. E/E1/E2/E3/E4/E5)
6. Mount the glass panels (Fig. F/F1/F2)
۰ Do not tighten too much!
7. Mount the washstand (Fig. G/G1)
8. Install the tap (Fig. H)
۰ Warning: Use the enclosed rubber seal.
۰ Do not overtighten the tap!
9. Fasten the pane of glass (Fig. I)
10. Mount the doors and drawers (Fig. J/J1/J2)
11. Aligning the doors (Fig. K/K1/K2/K3)
12. Adjusting the drawer (Fig. K4/K5/K6/K7)
13. Replace fitting (Fig. K8/K9/K10)
B/B1)
