SAFETY ADVICE

• Please read through the mounting instructions carefully
before mounting in the bathroom.
• The mounting must only be done by experts.
• Warning: defective mounting is dangerous!
• Check whether the wall is suitable for the mounting and
that the fasteners are strong enough for the forces involved.
• The enclosed fastening material is only suitable for solid
walls of sufficient load-bearing strength.
• In the case of different wall conditions (e.g., plasterboard or
lightweight walls), a different attachment must be made by
the customer which is appropriate to the load.
• Electrical installations should only be carried out by a
specialist electrician DIN VDE 0100-701 (VDE 0100-701):2008-10.
• Electrified, mirrored cabinets and flat mirrors must be locat-
ed at a minimum distance of 600 mm away from the bath or
shower.
• The safety regulations and standards of the particular coun-
tries must be observed.
IMPORTANT INFORMATION
• Inspect the packaging for external damage when it is delivered.
• Please check the number of bathroom cabinets supplied and
the associated sets of ironmongery (screws, cover caps,
handles, etc.) against the delivery note or the article's label
on the packaging.
• Caution: only remove the protective caps on the mirrored
cabinet's doors after mounting the doors, in order to avoid
damaging edges of the mirrors.
• Use suitable spacers or distance blocks to even out the
existing differences in level caused by coverings applied to
the walls, e.g., partial tiling.
• Reinforce any walls of insufficient load-bearing strength.
• The drilled dimensions are measured from the FFL according
to the dimensioned layout.
• Fasten the cabinets with the suspension rails:
- tall cabinets (600 mm width)
- Washstand base cabinet
- Highboard
- Vanity unit with drawer
• Always fasten the hanging bar to the wall with 2 screws!
• The horizontal spacing between the cabinets can be chosen
freely.
• Pay attention to the assembly and installation instructions
(additionally enclosed).
TOOLS
• Drill and battery-operated screwdriver
• Stone drill bit of 8 mm dia
• Wood drill bit of 4 mm dia, 5 mm dia
• Folding metre rule and measuring tape
• Spirit level
• Screwdriver with a 3.5 mm tip for Phillips screws
• Screw clamps
• Pencil
• Silicone sealant (transparent and solvent-free)
Slim Line Slim Line

MAINTENANCE INSTRUCTIONS

• Caution: do not use any chemicals, aggressive detergent
paste or scouring powder.
• The best way of cleaning the cabinet is to use a damp cloth
with some mild washing-up liquid.
• Take care that no residue from droplets remains on the lower
edge of bathroom cabinets.
• Polish the mirror with a damp cloth or chamois leather.
• The washbasin can be easily cleaned with any of the usual,
non-abrasive cleaning agents.
• Ventilate regularly in order to prevent the mould from forming.
KEEP THE INSTRUCTIONS IN A SAFE PLACE
i
Caution: keep the instructions safely because they contain
information about installing and operating the products!

MOUNTING SEQUENCE

i
For the figures, see the attachment
1. Remove the doors and drawers (Fig. A/A1)
2. Mount the lamps (Fig. B/B1/B2)
The mains wire should not be live!
3. Hang up the furniture (Fig. C/C1/C2/C3)
٠ Mirror cabinet/flat mirror
٠ Tall cabinets, upper cabinet centre cabinets
٠ Highboard
٠ Shelves
٠ Washstand vanity unit
٠ Base cabinet
٠ Washstand
4. Align furniture (Fig. D/D1/D2/D3/D4/D5/D6)
5. Mount the washstand
٠ Sawing of cut-out for washstand (Fig. E)
٠ Attaching shelf for washstand (Fig. E1)
٠ Mounting of shelf (Fig. E2)
٠ Bond the washbasin to the shelf (Fig. E3)
٠ Press washbasin tightly together with the shelf (Fig. E4)
٠ Seal the washbasin (Fig. E5)
6. Install the tap (Fig. F)
٠ Warning: Use the enclosed rubber seal.
٠ Do not overtighten the tap!
7. Stick on the shelf (Fig. G)
8. Mount the doors and drawers (Fig. H/H1/H2)
9. Aligning the doors (Fig. I/I1/I2/I3)
10. Adjusting the drawer (Fig. J/J1/J2)
11. Mount the mirror grip (Fig. K/K1)
