SAFETY ADVICE

• The mounting must only be done by experts.
• Warning: defective mounting is dangerous!
• Check whether the wall is suitable for the mounting and
that the fasteners are strong enough for the forces involved.
• Please read through the mounting instructions carefully
before mounting in the bathroom.
• The enclosed fastening material is only suitable for solid
walls of sufficient load-bearing strength.
• Electrical installations should only be carried out
by a specialist electrician DIN VDE 0100-701 (VDE 0100-
701):2008-10.
• Electrified, mirrored cabinets and flat mirrors must be locat-
ed at a minimum distance of 600 mm away from the bath or
shower.
• The safety regulations and standards of the particular coun-
tries must be observed.
IMPORTANT INFORMATION
• Inspect the packaging for external damage when it is delivered.
• Please check the number of bathroom cabinets supplied and
the associated sets of ironmongery (screws, cover caps,
handles, etc.) against the delivery note or the articleʼs label
on the packaging.
• Caution: only remove the protective caps on the mirrored
cabinetʼs doors after mounting the doors, in order to avoid
damaging edges of the mirrors.
• Use suitable spacers or distance blocks to even out the
existing differences in level caused by coverings applied to
the walls, e.g., partial tiling.
• Reinforce any walls of insufficient load-bearing strength.
• The drilled dimensions are measured from the FFL according
to the dimensioned layout.
• With open shelves, the lateral distance from the bore hole to
the body edge is 50 mm
• Only use the screws which have been supplied.
• Fasten the cabinets with the suspension rails:
- Tall cupboard (600 mm width)
- Washstand base cabinet (with width 900 mm)
• Always fasten the hanging bar to the wall with 2 screws!
• The horizontal spacing between the cabinets can be chosen
freely.
• Do not screw fittings and drain set too tight.
TOOLS
• Drill and battery-operated screwdriver
• Stone drill bit of 8 mm dia.
• Wood drill bits of 4 mm and 5 mm dia.
• Folding metre rule and measuring tape
• Spirit level
• Screwdriver with a 3.5 mm tip for Phillips screws
• 10 mm wide open-jawed spanner
• Screw clamps
• Pencil
• Silicone (solvent-free)
Swing

MAINTENANCE INSTRUCTIONS

• Caution: do not use any chemicals, aggressive detergent
paste or scouring powder.
• For cleaning furniture, it is best to use a soft, damp cloth
with a little detergent.
• Take care that no residue from droplets remains on the lower
edge of bathroom cabinets.
• Polish the mirror with a damp cloth or chamois leather.
• The washbasin can be easily cleaned with any of the usual,
non-abrasive cleaning agents.
KEEP THE INSTRUCTIONS IN A SAFE PLACE
i
Caution: keep the instructions safely because they contain
information about installing and operating the products.

MOUNTING SEQUENCE

i
Illustrations in the appendix
1. Remove doors and drawers (Fig. A/A1)
2. Suspending the cabinets
-Mirror cabinet set 1200/1400/1800 mm
Hang/Align mirror cabinet set 750/900 mm
(centre of the mirrored cabinet =
centre of the water supply connection)
Hang/Align mirror cabinet/shelf 300/500 mm
Connect the mirror cabinet set together (Fig. B)
Attach cornice and screw
Connect lamps (Fig. C/C1)
The electrical mains supply cable must be voltage-free!
- Hang/Align mirror cabinet 900 mm (alternative)
Connect lamps (Fig. C2)
The electrical mains supply cable must be voltage-free!
- Except large area mirror (alternative)
Connect lamps (Fig. C3)
The electrical mains supply cable must be voltage-free!
- Hang/Align washbasin vanity units
(centre of the washstand base cabinet =
centre of the water supply connection)
- Connect washbasin vanity units together (Fig. B)
- Tall cabinets, wall cabinets, medium cabinets, highboard
units, vanity units
3. Aligning the cabinets (Figs. D/E/F)
4. Mount fitting board (Fig. G)
5. Mount washstand (Fig. H/H1)
6. Screwing on the shelf (Fig. I)
Warning: do not drill through the shelf!
7. Affixing of the fitting (Fig. J)
∙Caution: Use attached rubber seal.
Do not tighten fitting too firmly!
8. Mount doors and drawers (Fig. K/K1)
9. Aligning the doors (Fig. L/L1/L2)
10. Adjusting the drawer (Fig. M)
11. Mount mirror cabinet door handles (Fig. N)
12. Set flap brake (Fig. O)
CHANGING THE FLOURESCENT TUBE
i
Figures: page 28 (Figs. P/P1)
