Overview of the ON-OFF controller

6
4-
Ø
(for mounting)
OI-744-05EG
116
160
148
122
5 diameter holes
128
80
47
4- 5.5 diameter holes (for mounting)
Ø
Z-view (back side)
* In order to mount the ON-OFF controller flush with the wall, an opening
measuring 128 mm × 128 mm is necessary.
Electrical component box
Control unit
14 69
(6)
Mounting plate
(for flush mounting)
Hole for electrical wiring
Rear plate
Unit: mm
Z
Fig. 1
