We would like to thank you for purchasing our air cooler. The Vento Comfort Iceberg is a new, economical
hi-tech product which is easy to use and has practical functions. Other well-known models were used as the
basis for its development and design.
Firstly, the water reservoir of the air cooler is filled with tap water. The cool blocks supplied, or ice cubes, can
be added to the water to speed up the cooling of the airflow. The ambient air flows across the rotating filter,
which moves through the water so that a cool stream of air is discharged. When the water evaporates, it
absorbs ambient heat and the ambient temperature sinks.
In contrast to conventional electrical fans, which only move the ambient air, or an air conditioning device
which often reduces the ambient temperature too severely, the air cooler creates a pleasant level of cooling.
In addition, the device has two filter screens, which remove microparticles and bacteria from the airflow, so
that healthy air is produced. Another feature of this air cooler is its energy-saving method of operation.
The energy costs remain low, as is the case with an electrical fan. You can adjust the almost naturally cool
airflow to suit your requirements via the control panel.
Before using the device, please ensure that you read the Operating Instructions carefully to ensure you obtain
the maximum service life from the appliance.
List of contents
1. Components and Functions of the Appliance
2. Before Use
3. Technical Information
4. Safety Instructions
5. Cool blocks
6. Operation
7. Schematic Diagram
8. Cleaning
9. Storage
10. Care Instructions
11. Troubleshooting
12. Warranty
- 92 -

1. Components and Functions of the Appliance

1
15
5
2
3
7
6
4
1) Air outlet grille
This is the outlet opening for the cool stream of
air.
2) Ventilation louvres
By adjusting the ventilation louvres using the
handle, you can set the direction of the air flow.
3) Horizontal, tilting louvre
The angle of the automatic tilt is 100°.
4) Water level gauge
The gauge indicates the height of the water level
in the water reservoir.
5) Control panel
The indicator lights for the timer, tilting, cooling,
on/off and speed switches are located on the
control panel.
6) Mains cable
Length 2 m.
7) Water level gauge
The water reservoir is filled via the water filling
inlet. The water capacity is 6.5 l.
8) Air inlet opening
The ambient air enters here.
10
9
11
8
12
13
14
9) Filter holder
Protects and holds the filter.
10) Filter
Antibacterial DEW filter (optional)
11) Recessed grip
The recessed grip enables the appliance to be
moved.
12) Water filling inlet
The water filling inlet is used to fill the water
reservoir.
13) Castors
The appliance can be easily moved on the
castors.
14) Water drainage stopper
Remove the water drainage stopper to empty
the water from the water reservoir.
15) Remote control
