8.5. The aluminium filter, holding oil
and dust from the air, is clogged and
should be washed after being soaked
in hot water with an effective detergent
once every 1.5 to 2 months. Changing
the control of the filter after washing
does not affect the quality of its work.
8.6. To remove the aluminium
filter (Fig. 6), press the spring lock of
the aluminium filter 1 and remove it.
Extract the pull-out panel with filter
2 and remove the aluminium filter 3.
The filter installation is performed in
reverse order. Do not install the filter
after washing until it is completely dry.
Fig. 6
Replacement of the lighting lamp.
8.7 To replace the lamp, it is
necessary to remove aluminium filter
1, pull out the panel with the filter 2,
pull the holder of the bulb socket, so
that the lamp 3 came out of the body
of cooker hood, holding the bulb socket,
lightly press the lamp in the direction
of the bulb socket and, turning it
counterclockwise, take out from the
TECHNICAL PASSPORT
body of the cooker hood (Fig. 7). Insted?
it is necessary to install a new one with
the same characteristics and install an
aluminium filter 1.
Fig. 7
Aluminium filter removing
