SMA DATA MANAGER L EDML-10 Schnelleinstieg Seite 9

SMA Solar Technology AG
Symbol Explanation
No function
No function
Operation button
Enables the restart of the product
Operation LED
Indicates whether the product is in operation.
Internal Memory
The symbol and LED signalize the status of the data transmission of the internal
storage system.
No function
No function
Grounding conductor
This symbol indicates the position for connecting a grounding conductor.
Ground
This symbol indicates the position for the connection to ground.
WEEE designation
Do not dispose of the product together with the household waste but in accor-
dance with the disposal regulations for electronic waste applicable at the in-
stallation site.
The product is suitable for indoor installation.
No function
CE marking
The product complies with the requirements of the applicable EU directives.
RoHS labeling
RoHS
The product complies with the requirements of the applicable EU directives.
Quick Reference Guide
3 Symbols on the Product
EDML-10-IS-xx-11 9
