2.4 Configuration of OGM Commander-Software
NOTICE!
The software is only available in english language!
To communicate with the OGM
interface (Fig. 1 , Pos. 9) must be set in the software!
1
2
12
6
7
8
9
10 11
Fig. 1: Configuration of OGM Commander-Software
1 Display of the detected type
2 Switching the output polarity of the
PLC pulses
3 Start new calibration
4 Safe configuration at PC
5 Load configuration from PC
6 Impulse frequency ul/pulse
7 Number of pulses per rotation
Intended use and installation
Plus
, the correct COM
3
A
8 Number of rotations per pulse
9 COM interface of the PC
10 Read data from the OGM
11
Send data to the OGM
12 Number of calibrations
13 Exiting the software
A Selecting the pulse display
5
4
5
13
Plus
Plus
