Cognex In-Sight CIO-MICRO Kurzanleitung Seite 6

8
7
6
OR
4
Legend*
1 = Power Wires
2
2 = Frame Ground Wire
3 = Input and Output Wires
5
4 = CC-Link Wires
5 = RS-232 Serial Cable
6 = RJ-45 LAN Cable
7 = I/O Module Cable
8 = Ethernet Cable
1 3
*The legend numbers also correspond with the
numbered Installation steps.
4
