F R O N T PA N E L
1. Power button
2. Power LED
3. SATA LED
4. WiFi LED
5. Memory card reader (SD/SDHC/SDXC)
6. Headphone/Audio Out jack
7. Microphone jack
8. USB 3.1 Type-C
9. USB 3.0 port
R E A R PA N E L
1. WiFi antenna connector
2. LAN (RJ45) ports
3. USB 3.1 ports
4. DisplayPort
5. HDMI port
6. Power input (DC19V)
S E T T I N G U P YO U R ZOTAC Z B OX N A N O
1. Connecting antenna for Wi-Fi
2. Connecting to a wired home network
3. Connecting USB 3.1 devices
4. Connecting a DisplayPort display
5. Connecting an HDMI display
6. Connecting the power adapter and turning
on the system
6 7
5
1
2 3 4
8
2
4
3
1
3
5
2 4
1
3 3 5 6
1
2
3
4
5
9
6
6
3
