Divar 2 | Operation Manual | Front panel controls

Front panel controls

Indicators
The power indicator lights to indicate that power is being supplied to the
unit.
The indicators across the top of the unit light or flash to alert you to various
operating conditions.
Record - lights when the unit is recording video.
Network - lights when a remote user is connected to the unit.
Alarm - flashes when an alarm is detected.
Motion - flashes when motion is detected in a camera signal.
Video loss - flashes when a video loss condition is detected for a
camera input.
Divar
Bosch Security Systems
Keys
The keys on the front panel can be used for controlling primary functions or
alternate functions. Symbols for the primary functions are shown above the keys.
Symbols for the alternate functions are shown below the keys.
The alternate functions are activated by first pressing the ALT key
the desired key. When the alternate function mode is active, the light below the
ALT key is lit.
The unit automatically exits the alternate mode if the monitor A key
monitor B key or sequence key
operate according to their alternate function.
EN | 4
and then
,
is pressed. When in a menu, the keys
