Motherboard Layout
1
CPU_FAN1
25
CI1
1
USB 2.0
Ps2
T: USB0
Keyboard
B: USB1
USB 2.0
T: USB2
B: USB3
USB 3.0
T: USB2
B: USB3
24
23
1
CPU Fan Connector (CPU_FAN1)
2
CPU Fan Connector (CPU_FAN2)
3
ATX Power Connector (ATXPWR1)
4
Chassis Speaker Header (SPEAKER1)
5
2 x 240-pin DDR3 DIMM Slots
(Dual Channel: DDR3_A1, DDR3_B1)
6
Chassis Fan Connector (CHA_FAN1)
7
CPU Socket
8
System Panel Header (PANEL1)
9
USB 2.0 Header (USB_45)
10
USB 2.0 Header (USB_67)
11
Consumer Infrared Module Header (CIR1)
12
SATA3 Connector (SATA3_3)
2
2
CPU_FAN2
DDR3_B1 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
Dual Graphics
SOCKET FM2
Top:
RJ-45
CLRCMOS1
1
HDMI_SPDIF1
1
USB3_0_1
AUDIO
CODEC
FM2A75M-ITX
HD_AUDIO1
21
22
20
19
ASRock FM2A75M-ITX R2.0 Motherboard
3
ATXPWR1
X
Fast RAM
DX11
RoHS
64Mb
AMD
BIOS
A75 FCH
Front USB 3.0
(Hudson-D3)
Chipset
PCIE1
18
17
13
SATA3 Connector (SATA3_4)
14
SATA3 Connector (SATA3_1)
15
SATA3 Connector (SATA3_2)
16
Southbridge Controller
17
SPI Flash Memory (64Mb)
18
PCI Express 2.0 x16 Slot (PCIE1)
19
USB 3.0 Header (USB3_0_1)
20
ATX 12V Power Connector (ATX12V1)
21
Front Panel Audio Header (HD_AUDIO1)
22
HDMI_SPDIF Header (HDMI_SPDIF1)
23
Clear CMOS Jumper (CLRCMOS1)
24
CPU Heatsink Retention Module
25
Chassis Intrusion Header (CI1)
4
SPEAKER1
1
5
CHA_FAN1
6
7
PANEL 1
8
1
9
USB_45
1
10
USB_67
1
11
1
CIR1
SATA3_4
SATA3_3
12
13
SATA3_2
SATA3_1
14
15
16
