Dimensioni d'ingombro / Overall dimensions
Dimensions d'encombrement / Abmessung
115
Fig. 2
Trasformatore (solo su C2V)
Transformer (only on C2V version)
Transformateur (seul. P230)
Trasformator (Nur V2)
Fusibile F1
Fuse F1
Fuse F1
SicherungF1
Morsetti Alimentazione 230 Vac
Modelli *C2V
Power supply terminal blocks
230 Vac Types C2V
Bornes alimentation 230Vac
modéles P230
Spannungsversorgung
230VAC SEL2641R433V2
Relè Verde
Green relay
Relais vert
Leistungsrelais
52
140
Pulsante PV- LED LV
PV push button- LED LV
Bouton PV- LED PV
Taster PV- LED PV
F1
1
2
3
4
5
N
Ph
230 Vac
Contatti Relè Verde
Green relay contacs
Contacts relais vert
Kontakt grün
T H E S M A R T L I V I N G
Layout
PV
PR
LR
LV
10 11 12
6
7
8
9
Contatti Relè Rosso
Red relay contacs
Contacts relais rouge
Wechselkontakt rot
Interassi / Drilling distances
Distances de perçage / Spurweiten
128
Pulsante PR- LED LR
PR push button- LED LR
Bouton PR- LED PR
Taster PR- LED PR
Buzzer
Buzzer
Buzzer
Summer
Antenna
Antenna input
Antenne
Antenne
13 14
Morsetti alimentazione12-24 Vac-
dcModelli *C2P
Power supply terminal blocks
12-24 Vac-dc Types C2P
Bornes d'alimentation 12-24 Vac-Vdc
modéles P230
Spannungsversorgung 12-24 VAC-DC
SEL2641R433C2
104
Fig. 3
Fig. 4
