DEUTSCH NEDERLANDS ENGLISH ITALIANO FRANÇAIS Hersteller Wörlein GmbH Tel.: +49 9103/71670 Gewerbestrasse 12 Fax.: +49 9103/716712 D 90556 Cadolzburg Email. info@woerlein.com GERMANY Web: www.soundmaster.de DAB80...
Seite 2
Sicherheits- / Umwelt- / Aufstellhinweise Achten Sie darauf, dass im Betrieb das Netzkabel HINWEIS ZUM UMWELTSCHUTZ niemals nass oder feucht wird. Das Netzkabel darf Dieses Produkt darf am Ende seiner Lebensdauer nicht über den normalen Haushaltsabfall entsorgt werden, sondern muss an nicht eingeklemmt oder anderweitig beschädigt einem Sammelpunkt für das Recycling von elektrischen und werden.
DAB80 / Deutsche Bedienungsanleitung BEDIENELEMENTE Lautstärkeregler 2.1 Ein/Aus | Funktionsauswahl 2.2 Automatischer Sendersuchlauf, NAP Timer, EQ 2.3 Information und Menü 2.4 Displayhelligkeit | LED Licht 2.5 Speichern 2.6 Station zurück | Suchlauf rückwärts 2.7 Play/Pause | Enter 2.8 Station vor | Suchlauf vorwärts...
DAB80 / Deutsche Bedienungsanleitung Automatische Standby-Schaltung (ERP) Das Gerät schaltet nach 15 Minuten automatisch in Standby wenn kein Audio-Signal vorhanden ist. Um das Gerät wieder einzuschalten, drücken Sie die “ | MODE” Taste. GRUNDBEDIENUNG GERÄT EIN-/AUSSCHALTEN Drücken Sie die “...
Seite 5
DAB80 / Deutsche Bedienungsanleitung Information (Info) Drücken Sie wiederholt die “Info | Menu” Taste, um die nachfolgenden Informationen des gegenwärtigen Senders anzuzeigen: ➢ DLS (Dynamic Label Segmenting) ➢ Audio Bit-Rate ➢ Signalstärke ➢ Netzbetrieb/Akkubetrieb ➢ PTY (Programmtyp) ➢ Uhrzeit ➢ Kanal/Frequenz ➢...
Seite 6
10 Meter beträgt. Eine andere Umgebung kann sich auf den Arbeitsabstand auswirken. 1. Wählen Sie die Funktion “Bluetooth” (“Bluetooth Paarung” wird im Display angezeigt). 2. Aktivieren Sie die Bluetooth-Funktion an Ihrem Bluetooth-Gerät und wählen Sie „DAB80“. Nach erfolgreicher Verbindung zeigt das Display “Bluetooth Verbunden” an. 3. Drücken Sie die “...
DAB80 / Deutsche Bedienungsanleitung 1. Wählen Sie die Funktion “Aux” (“AUX IN” wird im Display angezeigt). 2. Schliessen Sie Ihr externes Gerät mit einem Aux-Kabel an den Aux-Eingang auf der Rückseite des Gerätes an (Öffnen Sie dazu das Handyfach auf der Rückseite).
Safety, Environmental and Setup Instructions No objects filled with liquids, such as vases, ENVIRONMENTAL PROTECTION Do not dispose of this product with the normal household shall be placed on the apparatus. waste at the end of its life cycle. Return it to a collection ...
DAB80 / English Instruction Manual LOCATION OF CONTROLS Volume Control Control button 2.1 Power On/Off | Mode select 2.2 Automatic station search, NAP Timer and 2.3 Information and manual 2.4 Display backlight 2.5 Memory 2.6 Select lower station preset | search down 2.7 Play/Pause | Enter...
DAB80 / English Instruction Manual ERP power management The unit will turn off automatically after about 15 minutes in standby mode if there is no audio signal. To turn on the unit again press the “ST/BY / MODE” button. BASIC OPERATIONS POWER ON / OFF Press the “...
Seite 12
DAB80 / English Instruction Manual Information (Info) When the radio station is playing, press the “Info | Menu” button repeatedly to cycle through the information broadcasted by the radio as follow: ➢ DLS (Dynamic Label Segmenting) ➢ Audio Bit Rate ➢...
Seite 13
Different environment may have effect on the working distance. 1. Select the mode “Bluetooth” (“Bluetooth pairing” is shown in the display). 2. Activate the Bluetooth function on your Bluetooth device and select “DAB80”. When the connection was successful the display show “Bluetooth Connected”.
DAB80 / English Instruction Manual When stay on standby mode, press “AMS | EQ | NAP”, the display show NAP Timer < Off>. Press the button repeatedly to select the desired time 10, 15, 30, 45, 60, 90, 120, Off and press “Enter”...
Consignes de sécurité, d’environnement et d’installation PROTECTION DE L’ENVIRONNEMENT Un câble de réseau ou une prise abimés Ne jetez pas ce produit avec les ordures ménagères doivent être immédiatement remplacés par lorsqu’il est usagé. Retournez-le à un point de collecte un centre agréé.
DAB80 / Français Manuel d’instructions EMPLACEMENT DES BOUTONS Contrôle du volume 2.1 Marche/Arrêt | Sélection de mode 2.2 Recherche automatique des stations, minuterie de mise en veille, égaliseur 2.3 Menu Info 2.4 Luminosité de l’écran 2.5 Mémoire 2.6 Sélectionner la station présélectionnée précédente | Rechercher en descendant...
DAB80 / Français Manuel d’instructions INDICATEUR DE CHARGE DE LA BATTERIE Lorsque l’appareil est utilisé sur batterie, appuyez à plusieurs reprises sur la touche « INFO », jusqu’à ce que l’écran affiche « Battery xx » (xx = niveau de charge de la batterie).
Seite 18
DAB80 / Français Manuel d’instructions 3. Sélectionnez le numéro de la station à l’aide des touches « », puis appuyez sur « Enter » pour confirmer. Rappeler une station présélectionnée 1. Appuyez sur la touche « MEM ». L’écran affiche « Preset recall <X : (Empty) > » (X = numéro de la station mémorisée).
Seite 19
Un environnement différent peut avoir un effet sur la distance de fonctionnement. 1. Sélectionnez le mode « Bluetooth » (« Bluetooth pairing » s’affiche à l’écran). 2. Activez la fonction Bluetooth sur votre appareil Bluetooth et sélectionnez « DAB80 ». Lorsque la connexion est établie, l’écran affiche « Bluetooth Connected ».
DAB80 / Français Manuel d’instructions L’appareil est également doté d’une fonction mains libres. Si vous avez connecté un téléphone portable en Bluetooth et que vous recevez un appel, appuyez sur la touche « Enter » pour prendre l’appel. Pour raccrochez, appuyez longuement sur la touche « Enter » .
DAB80 / Français Manuel d’instructions • Réinitialisation des réglages d’usine Une réinitialisation des réglages d’usine réinitialise tous les paramètres utilisateur aux valeurs par défaut. • Version du logiciel Affichez la version du logiciel qui est installée. SPÉCIFICATIONS TECHNIQUES : utilisez uniquement l’adaptateur fourni Alimentation Modèle...
Veiligheids-, milieu- en instellingsaanwijzingen MILIEUBESCHERMING In geval van bliksem moet de stekker Gooi dit product niet weg bij het huishoudafval aan onmiddellijk uit het stopcontact getrokken het einde van de levensduur ervan. Breng het product worden. terug naar een inzamelingspunt voor hergebruik van ...
Seite 23
DAB80 / Nederlands Gebruiksaanwijzing LOCATIE VAN BEDIENINGEN Volumeregeling 2.1 Aan/uit-knop | Modusselectie 2.2 Automatisch zenders zoeken, NAP-timer en EQ 2.3 Informatie en gebruikershandleiding 2.4 Achtergrondverlichting 2.5 Geheugen 2.6 Lagere voorafingestelde zender selecteren | Omlaag zoeken 2.7 Afspelen/Pauzeren | Uitvoeren 2.8 Hogere voorafingestelde zender...
Seite 24
DAB80 / Nederlands Gebruiksaanwijzing BATTERIJ INDICATOR Druk, terwijl het apparaat in batterijmodus afspeelt, herhaaldelijk op de “INFO”-toets totdat er “Battery xx” (xx = batterijniveau) op het display verschijnt. Wanneer de batterij bijna leeg is en moet worden opgeladen, knippert het batterijpictogram in de rechterhoek van het display en verschijnt “Battery Low”...
Seite 25
DAB80 / Nederlands Gebruiksaanwijzing Zendergeheugens herroepen 1. Druk op de “MEM”-toets. Er zal “Preset recall <X: (Empty) > (X = vooraf ingesteld zendernummer) op het display worden weergegeven. 2. Selecteer met de “ ”-toets het zendernummer en druk op “Enter” om te bevestigen.
Seite 26
Verschillende omgevingen kunnen de gebruiksafstand inkorten. 1. Selecteer de modus “Bluetooth” (“Bluetooth pairing” verschijnt op het display). 2. Activeer de Bluetooth-functie op uw Bluetooth-apparaat en selecteer “DAB80”. Wanneer de verbinding tot stand is gebracht, verschijnt “Bluetooth Connected” op het display.
DAB80 / Nederlands Gebruiksaanwijzing 1. Selecteer de modus “Aux” (“AUX IN” verschijnt op het display). Sluit uw externe apparaat aan de achterkant van het apparaat aan met een Aux-kabel met Aux-aansluiting. (Hiertoe dient u de deur van het telefooncompartiment te openen).
Istruzioni di sicurezza, configurazione e ambienti di utilizzo caso temporali, disconnettere PROTEZIONE AMBIENTALE immediatamente il dispositivo dalla rete elettrica. Non smaltire il presente prodotto tra I normali rifiuti domestici al termine del suo ciclo di vita. Portarlo invece Il dispositivo può...
DAB80 / Italiano Manuale di istruzioni POSIZIONE DEI COMANDI Manopola volume 2.1 Accensione/Spegnimento | Seleziona modalità 2.2 Ricerca automatica delle stazioni, Timer NAP ed Equalizzatore 2.3 Informazioni e manuale 2.4 Retroilluminazione del display 2.5 Memoria 2.6 Seleziona stazione in preselezione più...
DAB80 / Italiano Manuale di istruzioni INDICATORE DELLA CARICA DELLA BATTERIA Quando il dispositivo è in uso ed è alimentato dalla batteria, premere ripetutamente il pulsante “INFO” fino a quando sullo schermo verrà visualizzato “Battery xx” (dove xx indica il livello della batteria).
Seite 32
DAB80 / Italiano Manuale di istruzioni 1. Selezionare la stazione radio desiderata. 2. Premere e lasciare premuto il pulsante “MEM” fino a quando verrà visualizzato sul display “Preset store <X: (Empty)>” (dove X corrisponde al numero della stazione in preselezione).
Seite 33
DAB80 / Italiano Manuale di istruzioni 1. Selezionare la modalità “FM”. 2. Premere il pulsante “AMS” per avviare una ricerca automatica. La radio salverà tutte le stazioni locali. Sintonizzazione automatica Premere e lasciare premuto il pulsante “ ” per avviare la sintonizzazione automatica. La radio interrompe la ricerca una volta trovata una radio ricevibile.
DAB80 / Italiano Manuale di istruzioni 1. Selezionare la modalità “Bluetooth” (sul display verrà visualizzato “Bluetooth pairing”). 2. Attivare la funzione Bluetooth sul proprio dispositivo selezionando “DAB80”. Una volta avvenuta la connessione, sul display verrà visualizzato“Bluetooth Connected”. 3. Premere il pulsante “...
DAB80 / Italiano Manuale di istruzioni • Selezionare la funzione “Set Time/Date”, “Auto update”, “Set 12/24 hour”, “Set date format” per regolare le impostazioni relative all’ora e alla data. • Lingua Scegliere la lingua desiderata del menu. • Ripristino delle impostazioni di fabbrica Il ripristino delle impostazioni di fabbrica riporta l’unità...
Seite 36
HERSTELLER / IMPORTEUR Wörlein GmbH Tel: +49 9103 71 67 0 Gewerbestraße 12 Fax: +49 9103 71 67 12 D 90556 Cadolzburg, Germany E-Mail: info@woerlein.com Hiermit bestätigt Wörlein GmbH, dass sich dieses Gerät in Wörlein GmbH potrjuje, da je ta naprava v skladu z Übereinstimmung mit den grundlegenden Anforderungen bistvenimi zahtevami in drugimi ustreznimi določbami und den übrigen einschlägigen Bestimmungen der Richtlinie...
