Celestron POWERSEEKER 50AZ Kurzanleitung Zur Einrichtung

Q U I C K S E T U P G U I D E
E N G L I S H
1 1
Unpack your telescope and verify that all parts are present.
Your PowerSeeker 50AZ includes: optical tube w/ lens shade
attached; tripod with center support bracket and accessory tray;
three eyepieces; a 3x Barlow lens, star diagonal, finderscope with
bracket, and a 1.5x image erecting eyepiece.
4
Check to ensure that all three legs are the same height once
extended to provide a level platform for the telescope.
7
Remove the threaded bolt from the underside of the telescope tube.
50AZ
#21039
2
To set up the tripod, spread the legs outward until they are fully
extended and push down center leg brace.
5 5 5
To mount the accessory tray, remove the fastener from the lower
support bracket.
8
Line up the hole in the mount with the holes on the underside of the
optical tube as shown above.
3
Extend the center portion of each of the three tripod legs down about
6 to 12 inches. Flip the tightening lever inward on each leg to secure
the extended leg in place.
6
Place accessory tray on lower support bracket and then tighten
fastener.
9
Replace the threaded bolt to secure the optical tube to the mount.
E NG LISH | 1
