5. Camera Connection
I. Basic Connection (Without PoE)
1) To attach external devices, such as sensors and alarms, connect them
to the extension I/O terminal block.
2) Connect the camera to a switch using an Ethernet cable.
3) Connect the supplied power cable to the camera and plug it into a
power outlet.
10
1: Power + 4.5V
2: Digital Output
3: Digital Input
4: Ground
5: RS485-
6: RS485+
