Selection buttons. These buttons are used to select a sequence, a playlist or to
enter numeric values.
Cancel button. This button is used to abort processes and to close dialogs.
Ok button. This button is used to confirm.
LCD screen.
Step backward within playlist.
Play a sequence or playlist.
Pause a sequence or a playlist.
Stop a sequence or a playlist.
Step forward whithin plalyist.
Record a sequence or a playlist.
Navigation buttons.
USB connector. Used to backup and restore the data of the
device. Also used for firmware updates.
AUX Port. Used for auxiliary devices like the CT-15b (External
Contacts).
DMX In A & B. Port for light control equipment.
DMX Out A & B. Port for DMX lighting fixtures.
Mains power cable.
