MOUNTING AND OPERATION

Action
Fine tuning of parallelism
Fine tuning of perpendicularity
Fine tuning of guide piece position
Adjusting the cutting depth
Cutting line
Switch operation
About the mode select function (*1)
Using the LED light
Using the cord holder
Attaching the long guide
(sold separately)
Attaching the guide (sold separately)
Attaching the fl uorine plate
(sold separately)
Attaching the dust collection adapter
(sold separately)
Cutting at right angles
Inclined cutting (+45° direction)
Inclined cutting (–5° direction)
Dismounting the saw blade
Mounting the saw blade
Selecting accessories
Safeguard Function
Overburden Protection
Temperature Protection

MAINTENANCE AND INSPECTION

1. Inspecting the saw blade
Since use of as dull saw blade will degrade effi ciency
and cause possible motor malfunction, sharpen or
replace the saw blade as soon as abrasion is noted.
2. Inspecting the mounting screws
Regularly inspect all mounting screws and ensure that
they are properly tightened. Should any of the screws be
loose, retighten them immediately. Failure to do so could
result in serious hazard.
3. Replacing supply cord
If the replacement of the supply cord is necessary, this
has to be done by the manufacturer of this agent in order
to avoid a safety hazard.
4. Motor unit maintenance
The motor winding is an important part of this tool. Avoid
damaging and be careful to avoid contact with cleaning
oil or water.
After 50 hours of use, clean the motor by blowing into the
ventilation holes of the motor housing with dry air from an
air gun or other tool (Fig. 28).
Dust or particle accumulation in the motor can result in
damage.
Figure Page
9
146
10 146
11 146
12 147
13 147
14 147
15 147
16 147
17 147
18 148
19
148
20 148
21 148
22 148
23 149
24 149
25 150
26 150
― 152
LED Light Display
On 0.1 second/off 0.1 second
On 0.5 second/off 0.5 second
(*1) About the mode select function
Each time the mode selector switch is pushed, the
operation mode changes.
When Silent mode is selected, the Silent mode indicator
lamp lights up.
Silent mode reduces maximum motor RPM enabling
effi cient work with less noise.
If the load increases while the motor is operating in
Silent mode, it automatically changes to Power mode.
Additionally, if the load decreases again, it automatically
returns to Silent mode.
In Power mode, no change is made to Silent mode even
when the load decreases.
Mode
Power
Silent
NOTE
○ You cannot change the mode unless the power plug is
connected to a receptacle and the switch is pulled once.
○ Even if the switch is turned on and off or the power plug
is disconnected and connected, this unit will maintain the
mode that you set.
LED LIGHT WARNING SIGNALS
(Fig. 27)
This product features functions that are designed to protect
the tool itself. While the switch is pulled and 3 seconds after
its release, if any of the safeguard functions are triggered
during operation, the LED light will blink as described in
Table 1. When any of the safeguard functions are triggered,
immediately remove your fi nger from the switch and follow
the instructions described under corrective action.
Table 1
Remove the cause of the overburdening.
Allow the tool to thoroughly cool.
5. Inspecting and maintaining the lower guard
Always make sure that the lower guard moves smoothly.
In the event of any malfunction, immediately repair the
lower guard.
For cleaning and maintenance, use an air gun or other
tool to blow clean the space between the lower guard
and gear cover as well as the rotation part of the lower
guard with dry air (Fig. 28).
Doing so is eff ective for the emission of chips or other
particles.
Accumulation of chips or other particles around the lower
guard may result in malfunction or damage.
WARNING
To prevent dust inhalation or eye irritation, wear
protective safety goggles and a dust mask when
using an air gun or other tool to clean the lower guard,
ventilation holes or other parts of the product.
6
No-load speed
4100 min -1
2500 min -1
Corrective Action
