Rane Zonetech Schnellstartanleitung Seite 3

Quickstart Guide (English)
Introduction
Thank you for purchasing the Zonetech. At Rane, performance and reliability mean as much to
us as they do to you. That's why we design our equipment with only one thing in mind—to
make your performance the best it can be.
Box Contents
Zonetech
(1) 6-pin 3.8 mm Euroblock input
(green, for audio inputs)
(3) 6-pin 3.8 mm Euroblock outputs
(orange, for zone outputs)
(1) 3-pin 3.8 mm Euroblock output
(orange, for zone outputs)
(1) 3-pin 3.8 mm Euroblock input
(black, for logic input)
Support
For the latest information about this product (documentation, technical specifications, system
requirements, compatibility information, etc.) and product registration, visit rane.com.
For additional product support, visit rane.com/support.
Setup
Items not listed under
Bluetooth
Device
Power
Computer
Router
Introduction > Box Contents
Paging
Remote
(e.g., Rane
RAD16z)
Master
Remote
(e.g., Rane
DR6)
®
Bluetooth Antenna
Power Cable
Quickstart Guide
Safety & Warranty Manual
Important: Visit
full User Guide.
are sold separately.
Mono Audio Inputs
(Microphones)
SOURCE SELECT
Zone
Powered
Remote Stereo
(e.g., Rane
Speakers
DRZH)
rane.com to download the
Stereo Audio
MASTER VOLUME
Inputs
ZONE 2 ZONE 2 ZONE 3 ZONE 3 INFO OPTION QUICK SELECT
ON/OFF SOURCE ON/OFF SOURCE STATUS DIMMER 1 CBL/SAT 2 Blu-ray 3 GAME 4 NETWORK
(Receiver, DVD
ENTER VIDEO L - AUDIO - R SETUP MIC
PHONES BACK SETUP
AUX 1
HDMI 7 5V/1A
AUX 1
Player, etc.)
Zone Amplifier
and Speakers
3
