4. Move the document feed tray towards the machine and move the hooks over the
mounting points (on both sides).
5. Let the document feed tray rest on the machine.

Installing the HCDF

To install the feeder tray of the HCDF:
1. Pull down lever A.
2. Hook in the feeder tray.
3. Release lever A.

Installing the MaxiFeeder

The maxiFeeder should be installed at the position of feeder no. 1 and/or 4. If you install
the maxiFeeder on position 4, you cannot use position 2 and 3 for document feeders.
To install the maxiFeeder as follows:
1. Lift the paper feed rollers with the front edge of the maxiFeeder.
