Get Familiar With Your Gear
⑤
⑥
④
⑧
⑦
NPS200
⑦
④
⑤
⑥
③
⑧
NPS400 NPS600
① Main Switch
② LCD Display
The LCD display can show the information on input/
output power, power remaining and more. (NPS400/
NPS600 can also show the runtime lasting and
charging time remaining. Short press the Main Switch
to switch between them when the power station is
being charged.)
③ DC Input
The power station can be recharged via the AC
adapter or the 100W solar panel.
④ DC Output Switch (For Controlling ⑤⑥ )
①
②
⑩
⑨
③
①
②
⑩
⑨
⑤ Cigarette Lighter Output
⑥ DC Output
⑦ USB Output Switch (For Controlling ⑧ )
⑧ USB Output
3 x USB-A Output
1 x USB-A QC Output (Marked with Orange)
1 x USB-C PD Output
⑨ AC Output Switch (For Controlling ⑩ )
⑩ AC Output
The power outlet shown in this manual is for
reference only. The actual product may vary
depending on regional variations.
-1-
Technical Specifications
Model
NPS200
Cell
18650 Li-ion Batteries
Capacity
196.56Wh (10.8V, 18.2Ah) (54600mAh)
DC Input
14.4V-26V, up to 10A (160W max)
AC Output
220V~0.68A 50Hz, Pure Sine Wave
Cig Lighter Output
12V⎓10A
DC Output
12V⎓10A
USB Output
5V⎓2.4A
USB QC Output
5V⎓2.4A / 9V⎓2A
USB-C Output
5V⎓3A / 9V⎓3A / 12V⎓3A / 15V⎓3A / 20V⎓3A
Operating Temperature
-10~40℃ (14~104℉)
Dimensions
209mm x 156.3mm x 137.3mm (8.23" x 6.15" x 5.41")
Weight
3.35kg (7.39lbs)
Accessories
AC Adapter, Power Cord
Model
NPS400
Cell
18650 Li-ion Batteries
Capacity
421Wh (10.8V, 39Ah) (117000mAh)
DC Input
14.4V-26V, up to 10A (160W max)
AC Output
220V~1.36A 50Hz, Pure Sine Wave
Cig Lighter Output
12V⎓10A
DC Output
12V⎓10A
USB Output
5V⎓2.4A
USB QC Output
5V⎓2.4A / 9V⎓2A
USB-C Output
5V⎓3A / 9V⎓3A / 12V⎓3A / 15V⎓3A / 20V⎓3A
Operating Temperature
-10~40℃ (14~104℉)
Dimensions
244mm x 187.7mm x 157.3mm (9.61" x 7.39" x 6.19")
Weight
5.68kg (12.52lbs)
Accessories
AC Adapter, Power Cord
Model
NPS600
Cell
21700 Li-ion Batteries
Capacity
594Wh (10.8V, 55Ah) (165000mAh)
DC Input
14.4V-26V, up to 10A (160W max)
AC Output
220V~1.36A 50Hz, Pure Sine Wave
Cig Lighter Output
12V⎓10A
DC Output
12V⎓10A
USB Output
5V⎓2.4A
USB QC Output
5V⎓2.4A / 9V⎓2A
USB-C Output
5V⎓3A / 9V⎓3A / 12V⎓3A / 15V⎓3A / 20V⎓3A
Operating Temperature
-10~40℃ (14~104℉)
Dimensions
244mm x 187.7mm x 157.3mm (9.61" x 7.39" x 6.19")
Weight
5.83kg (12.85lbs)
Accessories
AC Adapter, Power Cord
-2-
150W, 300W surge
Cig Lighter + DC Output:
Total 120W max
12W max each port
18W max
60W max
300W, 600W surge
Cig Lighter + DC Output:
Total 120W max
12W max each port
18W max
60W max
300W, 600W surge
Cig Lighter + DC Output:
Total 120W max
12W max each port
18W max
60W max
