OPERATION AND PROGRAMS

Insert the Safety key.
1.
Press the power button. The monitor will turn on.
2.
The program window will
display ENTER WEIGHT. Press the SPEED +/- or
INCLINE +/- buttons to input your weight.
Press ENTER to confirm your setting value. The
3.
program window will display SELECT PROGRAM
OR PRESS START.
Press PROGRAM button to select the desired
4.
program P1-P10 or U1-U3 with the SPEED +/- or
INCLINE +/- buttons.
In the program 1, the program window will display
5.
"MANUAL SPEED & INCLINE". In the program 2
to program 8, the program window will display profile
name. In the Program 9 to Program 10, the program
window will display "HRC WEIGHT LOSS". Press
the ENTER button to confirm your desired program.
The program window will display "ENTER YOUR
6.
WORKOUT TIME". The TIME window will flash.
Press + / - button to set up your desired time to do the
exercise. Press the ENTER button to confirm your
setting value.
The program window will display "ENTER YOUR
7.
WORKOUT DISTANCE". The DISTANCE window
will glitter, press + / - button to set up your desired
distance to do the exercise. Press the ENTER button
to confirm your setting value.
The program window will display "ENTER YOUR
8.
WORKOUT CALORIES". The CALORIES window
will flash, press + / - button to set up your desired
calories to do the exercise. Press the ENTER button to
confirm your setting value.
In the Program 1 to Program 8, press START to
9.
begin. Use the SPEED + / - keys to adjust the speed
and the INCLINE + / - keys to adjust the elevation. In
preset programs, you can change the resistance level
in the section of the profile you are performing at the
moment.
In the Program 9 to Program 10, the program
10.
window will first display "ENTER AGE". Press + /
- button input your age and ENTER to confirm. The
program window will display "ENTER TARGET
HEART RATE", press +/- button to input desired
target heart rate, then press ENTER to confirm
the target heart rate. You can now enter the target
time, distance and calories. Press the START to
begin exercise. Heart rate controlled exercises
enable training at a selected heart rate level. Heart
rate controlled exercises always require heart rate
measurement.
HRC ELEVATION = heart rate control is based on
automatically changing treadmill elevation. In this
mode, you need to adjust the speed manually.
HRC COMBINATION = heart rate control is based
on automatically, simultaneously changing treadmill
elevation and belt speed.
PROGRAMMING USER 1 TO USER 3 PROFILES
Press ENTER to confirm your desired user setting
1.
program.
The program window will display "ENTER YOUR
2.
WORKOUT TIME". The TIME window will flash.
AFNA_tread_Control_2.indd 7
O W N E R ' S M A N U A L • C O N T R O L
Press + / - button to enter your workout time. Press
ENTER to confirm your setting value.
The program window will display "ENTER YOUR
3.
WORKOUT DISTANCE". The DISTANCE
window will flash, press + / - button to set up your
desired distance to do the exercise. Press ENTER
to confirm your setting value.
The program window will display " ENTER YOUR
4.
WORKOUT CALORIES". The CALORIES
window will flash, press + / - button to set up your
desired calories to do the exercise. Press ENTER
to confirm your setting value. You can now edit the
profile levels.
In the program window, the first column of
a.
LED matrix will flash. Press SPEED + / - to set
up desired speed value and press incline + / - to
set up desired incline level.
Press the enter button to confirm your profile
b.
setting for first column.
Continue to finish all of the profile setting
c.
column by column.
Press START to begin exercise.
5.

SERVICE MENU

During the power ON position (initial mode), first
1.
hold the PROGRAM button then press the ENTER
button together to enter the Service Menu.
Incline window shows model number. Distance
2.
window shows software version, KCAL window
shows year. Time window shows date. Speed window
shows diameter of roller.
Press ENTER button window shows LDU version
3.
and ISP version
Press ENTER button enter KM/MILE switch mode,
4.
Press SPEED + - or INCLINE + - to select KM or
MILE.
Press ENTER button window shows total distance.
5.
Press ENTER button window shows total hour.
6.
Press ENTER button goes back to ON position
7.
– initial mode.

MAINTENANCE

The equipment is safe to use only when periodically
maintained and inspected for faults and wear.
Do not attempt any servicing or adjustment
CAUTION!
other than those described in this manual. Any other
servicing must be performed by an authorized service
representative. Check the tightness of all fixing
screws once a year. Do not overtighten.

CLEANING AND LUBRICATING THE TREADMILL

FAILURE TO LUBRICATE YOUR TREADMILL MAY
INVALIDATE THE PRODUCT'S WARRANTY!
Wipe the treadmill surfaces, especially the handlebars
and console from dust with a damp cloth or towel.
Do not use solvents. Use a small vacuum nozzle to
carefully vacuum around all visible components (belt,
running deck, side rails etc.). Also keep the area near
the treadmill clean. While in use, the treadmill gathers
dust that may cause problems in the operation of the
equipment.
