Fitting the wheels
1) T urn the radiator upside down and rest on a soft surface to
prevent scratching the radiator housing.
2) S crew the wheel plate onto the radiator, using the wire loops
and wing nuts provided.
3) P ush the castor wheels onto the wheel pins on the plate until
they "click" into place.
4) Turn the radiator back to its correct upright position.

Operation

1) T urn the thermostat (2) to the highest settings and switch
on the power (3). When the desired temperature has been
reached, turn back the thermostat until the indicator lamp
goes out.
2) S imply adjust the thermostat to retain the desired
temperature.
3) T he indicator lamp indicates whether or not the radiator is
working.
CLEANING
Before cleaning the radiator needs to be turned off and switched
off from power mains by pulling the plug from the wall socket.
Wait until the radiator sufficiently cools off.
External surfaces of the radiator may be cleaned by means of
a damp cloth.
Make sure no water gets through to the inside of the device. Do
not use any cleaning agents that may scratch surfaces.
IMPORTANT:
• D o not connect the radiator to a power source before
assembly.
• The radiator may be used only if in upright position.
• D o not scratch the radiator fins with sharp tools, since damage
to enamel may lead to corrosion.
• A free inflow of air provides maximum capacity of the
radiator. For that reason its holes shall not be covered.
• E xternal surfaces of the radiator are hot. Do not allow the
children to stay near the radiator without any attendance.
OS1607_OS1609_OS1611_IM_201.indd7 7
Technical data:
OS-1607 (7 fins) 1500W 220-240V~ 50/60Hz
OS-1609 (9 fins) 2000 W 220-240V~ 50/60Hz
OS-1611 (11 fins) 2500 W 220-240V~ 50/60Hz
4
Ecology – Environmental Protection
The "crossed-out trash bin" symbol on electrical
equipment or packaging indicates that the device
cannot be treated as general household waste and
should not be disposed of into containers for such waste.
Obsolete or broken-down electrical device should be .
delivered to special designated collection points, organized by
local public administration, whose purpose is to collect recy-
6
clable electrical equipment.
This way, each household helps reduce possible negative .
effects influencing natural environment and allows the .
reclaiming of materials which the product is made of.
Weight:
e
OS-1607: 10.6KG
e
OS-1609: 12.2KG
e
OS-1611: 13.8KG
