4. Installation

Brown
White
Green
Grey
Yellow
4. Installation
When surface mounting, align the SmartRelay so that the
antenna points towards the transponder (opposite the side
with the logo).
1. Unscrew the cover of the SmartRelay.
2. Remove the base with the circuit board.
3. Carefully release the circuit board from the snap lock of
the base.
4. Screw the bottom of the housing to the selected posi-
tion with two countersunk screws (not included in the
scope of delivery).
5. Reinsert the circuit board.
Connection for the col-
oured cables of an out-
sourced antenna.
Order code: SREL.AV
