GETTING STARTED

This charger can be used as both a battery charger and a power
supply with a 13.7 V output (13.7 V Supply). In the charge mode,
the charger will first charge the battery, and then maintain it fully
charged as long as it is connected. The charger, which features a
temperature compensator, provides optimum charging for lead-acid
batteries, whatever their type, size, within a range of 1-150 Ah, and
temperature. In the "13.7 V Supply" mode, the charger acts as a
power supply, and gives a continual power supply of max 7 A at
13.7 V.
1. Connect the charger's mains
plug to a power socket.
2. Connect the charger's red cable
clamp to the battery's positive ter-
minal post (+), and the black cable
clamp to the battery's negative
terminal post (-).
3. Select the correct mode, battery
size (Ah) and battery technology
(AGM/GEL or standard battery), or
13.7 V Supply.
4. When the green lamp shines
for the select mode, the battery
is fully charged.
