Rigging
- Mount the Pin spot with the mounting-bracket to your trussing system using an appropriate
clamp. The hole in the mounting bracket has a diameter of 10mm.
- For overhead use, always install a safety-rope that can hold at least 10 times the weight of the
fixture. You must only use safety-ropes with screw-on carabines. Pull the safety-rope through
the hole in the mounting bracket and over the trussing system. Insert the end in the carabine
and tighten the fixation screw.
- Adjust the desired inclination-angle via the mounting bracket and fix the bracket screws tightly.
- For Pin spot with plug, connect the fixture to the mains with the power plug.

Technical specifications:

MIRROR BALL MOTOR
Power supply: ..................................................................................... 230Vac / 50Hz
Power consumption: ............................................................................................ 4 W
Max Charge: ........................................................................................................ 3 kg
Max. Dia. of mirror ball: ....................................................................................30 cm
Rotation speed: ................................................................................................ 5 rpm
Diameter of base plate: .................................................................................110 mm
Height: .............................................................................................................58 mm
Weight: ..............................................................................................................0.3 kg
Par 36 lamp
Power supply: ...........................................................................................230V 50Hz
Power consumption: ........................................................................................... 30 W
Weight: .................................................................................................................1 kg
Dimensions (LxWxH): ................................................................150 x 120 x 115 mm
Fitting lamp: ....................................................................................... 6V 30W Par 36
Do not attempt to make any repairs yourself. This would invalid your warranty.
Do not make any changes to the unit. This would also invalid your warranty.
The warranty is not applicable in case of accidents or damages caused by inappropriate use or disrespect of the warnings
contained in this manual.
SkyTronic UK cannot be held responsible for personal injuries caused by a disrespect of the safety recommendations and
warnings. This is also applicable to all damages in whatever form.
