Power supply
Voltage
100-240 VAC; -15%/+10%;
50/60 Hz
Protection
8.0 A external circuit breaker
type C (250 VAC min) or 8.0
fast acting, high breaking fuse
(250 VAC min)
Typical Power
0.3 W typical on the RJ45 Link
Consumption
+ all external loads
Max. Power
8.0 A
Consumption
Overvoltage
II - 2.5 kV
Category
Hardware
Processor
STM32 (ARM Cortex™ M3)
MCU, 32 bit
CPU Speed
36 MHz
Memory
32 kB Non-volatile Flash
6 kB SRAM
Status
Green LEDs: Device & Power
Indicator
Status, LAN Tx & Rx
Environmental
Operating
+5°C to +40°C
Temperature
Storage
-20°C to +70°C
Temperature
Relative
+20 to 90% Non-condensing
Humidity
Altitude
< 2000 m
Pollution
2
Degree
Sunblinds Expansion Module
product specifications
Enclosure
Material
Colour
Dimensions
- with terminal
block covers
Shipping Weight 0.35 kg
IP
Installation
Inputs
Digital Inputs
(DI1, DI2,
DI3, DI4)
Outputs
Shade/
sunblind
Outputs
(BLIND1,
BLIND2;
BLIND3,
BLIND4)
Subnetwork
Communication RS-485
Cable
Connector
Topology
Flame retardant ABS
Blue casing
132 × 132 × 44 mm
132 × 182 × 44 mm
30 when equipped with strain
relief and terminal block cover
Direct din-rail mounting or
wall-mounting
Dry Contact 0-3.3 VDC
Same voltage as power supply
2.0 A max (inductive or
resistive load)
Current Peak 4 A max < 20ms
1: Sunblind UP command
2: Sunblind DOWN command
Cat 5e, 8 conductor twisted pair
RJ-45
Daisy-chain configuration
3
