Mode 2
Fixed frequencies 1
en
Festfrequenzen 1
de
f-Fix Select B0
f-Fix Select B1
f-Fix1
L
L
f-Fix2
H
L
f-Fix3
L
H
f-Fix4
H
H
Mode 3
One operating direction (FWD)
en
Eine Drehrichtung (FWD)
de
(EXTFLT → Mode 1)
Mode 4
Digital potentiometer 1
en
Digitales Potenziometer 1
de
Mode 5
Digital potentiometer 2
en
Digitales Potenziometer 2
de
(EXTFLT → Mode 1)
Mode 6
Digital potentiometer 3
en
Digitales Potenziometer 3
de
Mode 7
Fixed frequencies 2
en
Festfrequenzen 2
de
f-Fix Select B0
f-Fix Select B1
f-Fix1
L
L
f-Fix2
H
L
f-Fix3
L
H
f-Fix4
H
H
(EXTFLT → Mode 1)
Mode 8
Machine control 1
en
Maschinensteuerung 1
de
ENA → FWD; DIR = L
ENA → REV; DIR = H
Mode 9
Machine control 2
en
Maschinensteuerung 2
de
ENA → FWD; DIR = L
ENA → REV; DIR = H
(EXTFLT → Mode 1)
4/4
Eaton Industries GmbH, Hein-Moeller-Straße 7-11, 53115 Bonn, Germany
© 2014 by Eaton Industries GmbH,
Eaton.eu/documentation
0 V
+10 V
f
PNU
2
20 Hz
P-20
30 Hz
P-21
40 Hz
P-22
50 Hz
P-23
0 V
+10 V
0 V
+10 V
0 V
+10 V
0 V
+10 V
0 V
+10 V
f
PNU
2
20 Hz
P-20
30 Hz
P-21
40 Hz
P-22
50 Hz
P-23
0 V
+10 V
0 V
+10 V
