LASER DISTANCE METER
EN

PRODUCT DESCRIPTION

14
5
7
9
12
13 11 6
8
XP3 PRO CONDTROL
User manual
1. Display
2. Keyboard
3. Switch on the device / turn
on laser beam / single distance
measurement / continuous
1
measurement
4. - Addition/up/increase the
value/ flip through measuring
results in memory (forward)
5. Subtraction/down/decrease
the value/ flip through measuring
results in memory (backwards)
2
6. Timer/measuring unit
3
7. Calculation of area/wall
4
area/volume/ point-to-point
measurement
8
8. Calculations by tilt sensor and
Pythagoras' Theorem /stake-out
10
9. Bluetooth/reference point
10. Memory/switch on/off the
sound signal
11. Switch off the device /clear /
exit mode
12. Strap location
13. End-piece
14. Mini-USB connector for
charging
LASER DISTANCE METER
EN
Display
4 3
7
1
OPERATION
Insert/replace batteries
Insert batteries observing correct polarity. Use nickel-metal-hydride batteries.
Charge level is shown on display. Charge batteries when symbol
on the display. Use USB charger delivered in the set only.
Don't use the product while charging.
It takes approximately 4 hours to fully charge the batteries.
Switch on/off
Switch on: press .
Switch off: press and hold
Measuring unit
To select the appropriate measuring unit press and hold
required number of times.
Sound signal
To switch on/off sound signal press and hold
XP3 PRO CONDTROL
User manual
5
1. Main line
2. Additional lines
3. Indication of tilt angle
4. Indication of the mode
2
5. Indication of battery
charge level
6. Measuring unit
6
7. Reference point
for 1 sec.
for 2 sec.
appears
for 2 sec.
9
