INSTALLATION AND SWITCHING ON

1. Put the rubber sleeves into the two installation holes.
2. Put the fixing plate in position.
3. First, put the clamp onto the fixing panel, then fit the washers,
then insert the screws into the rubber sleeves (Do not tighten the
screws completely until the whole unit is fully installed).
4. Fit the seat and attach it using the fixing plate.
If fixed to a round angle
bowl, the integrated units
can be uninstalled:
Unscrew the screws inside
the lumps, then remove the
two integrated parts
MAKING THE CONNECTIONS
Installation (see diagram):
Connect the filter T to the water supply and tighten.
Connect the water inlet pipe to the T outlet.
Close the water inlet valve tightly.
FITTING THE BATTERIES
Remove the battery cover on the back of the remote control and insert 2 alkaline batteries.
Please note:
Remove the batteries if the appliance is not is use for a long period.
Removing the batteries will cancel any saved settings. Temperatures must be reprogrammed be-
fore subsequent use.
SWITCHING ON
Plug in the power supply.
Push the "power" button on the left hand side of the appliance; the power indicator will light up
bright red.
CHECKING LIGHT SIGNALS
Press the button and the
hold down the
Once seated, check that "Seat" indicator is lit up.
Press the button and check that the
CHECKING FOR POSSIBLE LEAKS
Check that there are no leaks in the pipes or nozzles.
NEW Notice_UK_DE_NL_SE_HD.indd 6
light signal should turn on. If it does not,
button to turn on the appliance.
This pipework can be connected to a cistern.
indicator is lit up.
If it is unused, fit end cap.
