TECHNICAL DATA

I n p u t s
Line IN L/ R
C o n n e c t o r XLR female (1=Ground; 2=+; 3=--)
Input design e l e c t ronically balanced & floating
Inp. impedance 47 kohms
S e n s i t i v i t y 0 dB
Max. input level + 24 dB
O u t p u t s
Parallel Out L/ R
C o n n e c t o r : XLR male (1=Ground; 2=+; 3=--)
Satellite L/ R
C o n n e c t o r : S p e a k o n
Active Cro s s o v e r
C rossover fre q u e n c y 130 Hz
Roll off 24 dB/ Octave
A m p l i f i e r s
Power output Subwoofer (Mono) 300 W/ 8 ohms at 1% THD
Power output per Satellite 150 W/ 4 ohms at 1% THD
S p e a k e r s
S u b w o o f e r
D r i v e r 1x 15" HK Audio Custom
Nominal impedance 8 ohms
Power handling nom. 150 W
Power handling pro g r. 300 W
Sensitivity 1W/1m axial 104 dB (half space)
Max. Sound pre s s u re 126 dB at 3% harmonic distortion (half space/ 1m)
® NL4 (pin 1+= +; pin 1--= --)
S a t e l l i t e
D r i v e r s 1x 8" plus Ceramic HF driver with 60°x40° horn
Nominal impedance 4 ohms
Power handling nom. 150 W
Power handling pro g r. 200 W
F requency re s p o n s e 100 Hz – 18 kHz, ±4 dB
D i re c t i v i t y H o r.±30° from 2 kHz to 20 kHz
Ve r. ±20° from 3 kHz to 20 kHz
C rossover fre q u e n c y 4,5 kHz (passive)
Sensitivity 1W/1m axial 101 dB (half space)
Max. Sound pre s s u re 117 dB at 3% harmonic distortion (half space/ 1m)
Dimensions & We i g h t s
S a t e l l i t e :
Width: 270 mm • Height: 425 mm • Depth: 230 mm
Weight: 8 kg
S u b w o o f e r :
Width: 540 mm • Height: 440 mm • Depth: 615 mm
Weight: 37 kg
S y s t e m :
Width: 540 mm • Height: 850 mm incl. wheels • Depth: 440 mm
Weight: 53 kg
O p t i o n s
Add- on Package
contains:
2x 7 m Speakon ® - cable
2x alu- speaker stands
Gigbag for cable and stands
