English
Connections
Twisted Pair – RJ45
Connect the UTP port of the media converter to
an RJ45 port on the network; e.g., to an Ethernet
switch. Cat5e or better cabling is recommended.
SFP+ Slot
This media converter requires an SFP+ transceiver
module that provides fiber optic connections.
1. Insert the transceiver into the media converter.
Next, install the fiber optic cable into
the transceiver.
2. Install the other end of the fiber optic cable into
an appropriate port in your fiber network.
Maximum length and fiber cable specification
depend on the model.
Setup
2
10G
Base-R
Fiber
Network
10GBase-T to 10GBase-R Media Converter
10 GB SFP+
10G RJ45
12 V (0.5 A)
