the rear suspension (fig. 9). To release it move the
bar up (fig. 10).
ATTENTION! The safety break should not be used
to slow the stroller down. It can only be used when
stationary.
ATTENTION! Never leave a child in the stroller
without the break activated.
CANOPY ASSEMBLY AND ADJUSTMENT
In order to attach the canopy, clip its catches into
the special slots mounted on the side stroller frame
(fig. 11). To remove it press the lever and slide out
the canopy catches (fig. 12).
In order to adjust the canopy to the desired
position move it forwards or backwards (fig. 13).
The canopy has an additional section. To unfold
it, open the zip in the rear part of the canopy and
push it forward.
ATTACHING AND REMOVING THE SAFETY
BAR
In order to attach the safety bar clip its catches into
the special slots mounted on the side stroller frame
(fig. 14). To remove the safety bar press the button
on the handles and pull up (fig. 15). No need to
remove the safety bar prior to folding the stroller.
FOOT REST ADJUSTMENT
The foot rest may be set to one of two positions:
sitting and lying. To set to the lying position, lift the
foot rest and slide out the metal support (fig. 16).
To set to the sitting position, slide the support in the
direction as indicated by the arrow (fig. 17).
ATTENTION! The foot rest is designed to support
the feet of a child. If the child is in a sitting position
the foot rest also has to be set to the sitting
position.
EN

BACKREST ADJUSTMENT

The stroller has a 4-position back adjustment. To
lower the backrest, pull the lever in the r ear of the
backrest and then set it to the required position
(fig. 18). To raise the backrest push it upwards.

SAFETY HARNESS

To put the five point safety harness on, connect the
shoulder straps with the hip straps and then slot
them into the central buckle attached to the groin
strap (fig. 19). Adjust all the straps and belts so
that they are snug with the child's body but at the
same time are not uncomfortable.
FOLDING THE STROLLER
Make sure the canopy is folded or removed before
folding the stroller (see: "canopy assembly and
adjustment").
To fold the stroller, press down and hold the
small button in the back section of the folding
mechanism (fig. 20a), press the large button in
the front section of the folding mechanism (fig.
20b) and push the stroller guiderail down until fully
folded (fig. 21).
