RL-Smart
| Lightweight rollator
3.3. Contents
After receiving the goods, please check the contents for completeness
right away. The content consists of:
• Outer package
• Rollator pre-assembled
• Instruction manual
3.4. Summary
Product overview RL-Smart (Fig. 2):
Handle
Brake with locking device
Backrest
Handle bar
Seat
Bag
Locking mechanism
Walking stick holder
(optional)
Steering wheel
Running wheel
26
4.

Assembly/adjustments

4.1. Unfolding

• Position the B+B Rollator in front of you in the direction of travel.
• Apply the parking brakes.
• To unfold the rollator, push the frame of the sit downwards (Fig. 3).
Make sure that the frame is laid out correctly and that it clicks into
place.

4.2. Folding up

• Apply the parking brakes.
• Hold the rollator firmly with one hand on the handle. With the
other hand, pull the strap on the seat upwards (Fig. 4).
• You need to push past the resistance of the locking mechanism.

4.3. Installing the functional bag

• The B+B Rollator is unfolded. Apply the parking brakes.
• Position yourself with your back towards the direction of travel in
front of the B+B Rollator.
• Pull the straps of the bag over the handle and slide these under the
pins (Fig. 5).

4.4. Adjusting the handles

• The B+B Rollator is unfolded. Apply the parking brakes.
• Loosen the nut (Fig. 6) and remove the fixation screw.
• Stand behind the B+B Rollator and allow your arms to hang loosely
down.
• Now insert the handles so they are at the height of your wrists.
2
Bischoff & Bischoff GmbH | 21.10.2019 - Revision: 1
RL-Smart
Lightweight rollator |
3
4
5
6
27
