Air Supply Requirements
1. Supply tool with 90 psig (6.2 bar) of clean, dry air. Higher pressure drastically reduces tool
life.
2. Connect tool to air line using pipe, hose, and fitting sizes shown in the diagram on page 12.
Lubrication
1. Use an air line lubricator with SAE #10 oil, adjusted to two (2) drops per minute. If an air line
lubricator cannot be used, add air motor oil to the inlet once a day.
2. Check clutch oil once each month. Use 1/3 oz. (10 ml) of SAE #30 oil or equivalent.
Operation
1. This impact wrench is equipped with a regulator to enable adjustment of output power. Turn
regulator knob counter-clockwise for maximum power, clockwise to reduce power.
2. When tightening nuts not requiring critical torque values, run nut up snug and then tighten
an additional one-quarter to one-half turn.
Noise & Vibration Declaration*
Sound pressure level 89 dB(A) impacting, 98 dB(A) freespeed, uncertainty 3 dB(A), in
accordance with ISO15744-2002. For sound power, add 11 dB(A).
2
Vibration value < 3.1 m/s , re. ISO 8662-7.
For making estimates of daily vibration exposures, useful information may be found in
CEN/TR 15350: 2006, "Mechanical vibration - Guideline for the assessment of exposure to
hand-transmitted vibration using available information including that provided by
manufacturers of machinery"
Maintenance
1. Disassemble and inspect air motor and impacting clutch every three (3) months if the tool is
used every day. Replace damaged or worn parts.
2. High wear parts are underlined in the parts list.
3. To keep downtime to a minimum, the following service kits, detailed on page 12, are
recommended: 2050524783 Tune-Up Kit
*These declared values were obtained by laboratory type testing in compliance with the stated standards and are not adequate for
use in risk assessments. Values measured in individual work places may be higher than the declared values. The actual exposure
values and risk of harm experienced by an individual user are unique and depend upon the way the user works, the workpiece and the
workstation design, as well as upon the exposure time and the physical condition of the user. We, Chicago Pneumatic, cannot be held
liable for the consequences of using the declared values, instead of values reflecting the actual exposure, in an individual risk
assessment in a work place situation over which we have no control.
To reduce risk of injury, everyone using, installing,
repairing, maintaining, changing accessories on, or
working near this tool must read and understand
these instructions before performing any such task.
The goal of Chicago Pneumatic is to produce tools that help you work safely and
efficiently. The most important safety device for this or any tool is YOU. Your
care and good judgment are the best protection against injury. All possible
hazards cannot be covered here, but we have tried to highlight some of the
important ones.
For Additional Safety Information Consult:
Your employer union and/or trade association.
US Department of Labor (OSHA); www.osha.gov; Council of the European
Communities europe.osha.eu.int.
"Safety Code For Portable Air Tools" (B186.1) available from: www.ansi.com
"Safety Requirement For Hand-Held Non-Electric Power Tools" available from:
European Committee for Standardization, www.cenorm.be
Air Supply And Connection Hazards
Air under pressure can cause severe injury.
Always shut off air supply, drain hose of air pressure and disconnect tool from air
supply when not in use, before changing accessories or when making repairs.
Never direct air at yourself or anyone else.
Whipping hoses can cause serious injury. Always check for damaged or loose
hoses and fittings.
Do not use quick disconnect couplings at tool. See instructions for correct set-up.
Whenever universal twist couplings are used, lock pins must be installed.
Do not exceed maximum air pressure of 90 psi (6.2 bar) or as stated on tool
nameplate.
Entanglement Hazards
Keep away from rotating drive.
Do not wear jewelry or loose clothing.
Choking can occur if neckwear is not kept away from tool and accessories.
Scalping can occur if hair is not kept away from tool and accessories.
Avoid direct contact with accessories during and after use. Gloves will reduce the
risk of cuts or burns.
Use only proper accessory retainers (see parts list). Use deep sockets wherever
possible.
Projectile Hazards
Always wear impact-resistant eye and face protection when involved with or near
the operation, repair or maintenance of the tool or changing accessories on the
tool.
Be sure all others in the area are wearing impact-resistant eye and face
protection.
Even small projectiles can injure eyes and cause blindness.
Use only impact wrench sockets and accessories in good condition. Sockets in
poor condition or hand sockets used with impact wrenches can shatter.
Always use the simplest hook-up possible. Long, springy extension bars and
RP9522B Impact Wrench
We, Chicago Pneumatic Tool Co. LLC, 13325 Carowinds Blvd., Charlotte NC, 28273 USA, declare
under our sole responsibility that the product to which this declaration relates, is in conformity with
the requirements of the Council Directive of June 1998 on the approximation of the laws of the
Member States relating to machinery (98/37/EC).
Machine Name RP9522B Impact Wrench
Machine Type Assembly Power Tool for Threaded Fasteners - No other use is
permitted.
Serial No. Tools with No. C-00501-2008 or higher
Technical Data
3/8" Sq. Dr. Std.
Air pressure 90 psi (6.2 bar)
Ult. torque @90 psi (6.2 bar) 90 ft.-lb. (122 Nm)
Harmonized Standards Applied EN792-6
National Standards Applied ISO 8662-7, ISO15744-2002
Name and Position of Issuer Bruno Blanchet, General Manager
Signature of Issuer
Date of Issue March 15, 2008
Limited Warranty: The "Products" of the Chicago Pneumatic Tool Company ("CP") are warranted to be free from defects in
material and workmanship for one year from the date of purchase. This Warranty applies only to Products purchased new
from CP or its authorized dealers. Of course, this Warranty does not apply to products which have been abused, misused,
modified, or repaired by someone other than CP or its Authorized Service Representatives. If a CP Product proves defective
in material or workmanship within one year after purchase, return it to any CP Factory Service Center or Authorized Service
Center for CP tools, transportation prepaid, enclosing your name and address, adequate proof of date of purchase, and a
short description of the defect. CP will, at its option, repair or replace defective Products free of charge. Repairs or
replacements are warranted as described above for the remainder of the original warranty period. CP's sole liability and your
exclusive remedy under this Warranty is limited to repair or replacement of the defective Product. (There Are No Other
Warranties Expressed Or Implied And CP Shall Not Be Liable For Incidental, Consequential, Or Special Damages, Or
Any Other Damages, Costs Or Expenses Excepting Only The Cost Or Expense Of Repair Or Replacement As
Described Above.)
© Copyright 2008, Chicago Pneumatic Tool Co. LLC
All rights reserved. Any unauthorized use or copying of the contents or part thereof is prohibited. This applies in
particular to trademarks, model denominations, part numbers and drawings.
Use only authorized parts. Any damage or malfunction caused by the use of unauthorized parts is not covered by
Warranty or Product Liability.
