● Operation
● Select polarity
Inspect the terminal device to establish
❑
the polarity that is required, or consult the
operating instructions of the terminal device.
See illustration A for positive polarity,
where outside is – and inside is +. Or see
illustration B for negative polarity, where
outside is + and inside is -
Move the polarity selector switch
❑
on your mains adapter to the relevant
position. Image C shows a positive polarity
with the selector switch down. Image D
shows a negative polarity with the selector
switch up.
● Select output voltage
Set the voltage selector switch
❑
supply voltage that is needed for your
terminal device.
CAUTION:
damage the connected terminal device.
An erroneous voltage can

Operation

switch
3
to the
4
GB 15
