Stage
5 MW0202 Round Wood Sidestay x2
TP803 Knightswood Triple Swing Frame
M8 x 25mm
Large washer
M8 x 70mm Coach screw x4
FA7184
PM1007 x1
FA8439
x4
SSEMBLY TIP
Drill 3mm
Pilot Holes
SSEMBLY TIP
SSEMBLY
TIP
M8 x 25mm
Make sure that the fixing points are centred on the legs.
M8 x 70mm
washer
TP Knightswood Swing Frames
13
