Stage
M8 x 25mm
4
Large washer
M8 x 70mm Coach screw FA7184
x4
x4
FA8439
TP803 Knightswood Triple Swing Frame
MW0200 Round Wood Leg x4
M8 x 70mm
M8 x 70mm
M8 x 25mm
washer
M8 x 25mm
washer
SSEMBLY TIP
Drill 3mm
Pilot Holes
SSEMBLY TIP
Use Mallet to
firmly locate leg
into Round Wood
Swing Bracket
TP Knightswood Swing Frames
12
