No. Description
1
Power Fan Connector (PWR_FAN1)
2
ATX 12V Power Connector (ATX12V1)
3
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
4
2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
5
ATX Power Connector (ATXPWR1)
6
USB 3.0 Header (USB3_2_3)
7
SATA2 Connectors (SATA2_0)
8
SATA2 Connectors (SATA2_1)
9
SATA3 Connectors (SATA3_0)
10
SATA3 Connectors (SATA3_3)
11
SATA3 Connectors (SATA3_2)
12
Chassis Fan Connector (CHA_FAN1)
13
System Panel Header (PANEL1)
14
SATA3 Connectors (SATA3_1)
15
Power LED Header (PLED1)
16
TPM Header (TPMS1)
17
USB 2.0 Header (USB6_7)
18
USB 2.0 Header (USB4_5)
19
Infrared Module Header (IR1)
20
Chassis Speaker Header (SPEAKER1)
21
Clear CMOS Jumper (CLRCMOS1)
22
COM Port Header (COM1)
23
SPDIF Out Connector (SPDIF_OUT1)
24
Front Panel Audio Header (HD_AUDIO1)
25
Chassis Fan Connector (CHA_FAN2)
26
CPU Fan Connector (CPU_FAN1)
27
CPU Fan Connector (CPU_FAN2)
2
